Nm500 Wear-Resistant Steel Plate
NM500 wear-resistant steel plates have a long service life, reducing equipment downtime for maintenance and lowering maintenance costs by 40-60%; they are also lighter than castings with equivalent protective performance, reducing equipment energy consumption by 10-15%. Leading China supplier control the source, providing complete quality traceability and supporting third-party testing to avoid substandard products.
The carbon content of NM500 wear-resistant steel plates is controlled between 0.28-0.32%, ensuring both hardness and avoiding brittleness, allowing them to withstand strong impact loads without easily cracking. The chemical composition table for NM500 wear-resistant steel plates is available; custom alloy ratios can be made for special applications: high-temperature resistant types increase tungsten (W) content (0.15-0.25%), while corrosion-resistant types increase chromium and nickel content (3.0-3.5% Cr, 1.0-1.5% Ni).
Chemical Composition Table
|
Element |
Content range: |
Functions |
|
Carbon (C) |
0.28-0.32% |
Improves hardness and wear resistance, forms carbide reinforcing phases |
|
Silicon (Si) |
0.50-0.70% |
Deoxidizer, solid solution strengthening, improves steel purity |
|
Manganese (Mn) |
1.20-1.60% |
Improves hardenability, refines grains, enhances toughness |
|
Chromium (Cr) |
1.80-2.20% |
Forms M7C3 type carbides, significantly improving wear resistance |
|
Molybdenum (Mo) |
0.20-0.40% |
Improves hardenability and tempering stability, enhances high-temperature strength |
|
Nickel (Ni) |
0.40-0.60% |
Improves low-temperature toughness, prevents cold brittleness |
|
Vvanadium (V) |
0.08-0.15% |
Refines grains, forms carbonitrides, improves strength |
|
Borne (B) |
0.0005-0.003% |
Trace amounts of boron significantly improve hardenability |
|
Sulfur (S) |
≤0.015% |
Reduces sulfur content, reduces hot brittleness |
|
Phosphorus (P) |
≤0.020% |
Controls phosphorus content, improves toughness |
Wear Resistance
Wear resistance is 3-5 times that of ordinary Q235 steel plate, 30-50% higher than NM400, and 50-80% higher than NM360.
Utilizing a quenching and tempering heat treatment process, a uniform martensitic structure is formed, and the dispersed carbide reinforcing phase provides long-lasting wear resistance.
Wet sand abrasion test (ASTM G105 standard) shows a wear rate of only 0.08 g/cm², far lower than ordinary wear-resistant steel.
Manufacturer's Core Service Capabilities
Customized Production: Customized thickness, size, and irregular shapes according to requirements; supports processing based on drawings.
One-Stop Deep Processing: Cutting, bending, and welding; ready for customer installation upon receipt.
Technical Support: Provides welding process guidance, installation scheme design, and on-site construction guidance.
Quality Assurance Service: Each batch includes material certificate and hardness/impact test report; supports third-party re-inspection.
Product Advantages
NM500 Wear-Resistant Steel Plate offers extremely high hardness (typically around 500 HBW), delivering superior abrasion resistance, excellent impact toughness, and long service life in severe working conditions such as mining, construction machinery, and heavy-duty material handling. It also helps reduce equipment wear, lower maintenance costs, and improve overall operational efficiency.
FAQ
1. What is NM500 Wear-Resistant Steel Plate?
NM500 is a high-hardness wear-resistant steel plate with a typical hardness of around 500 HBW, designed for extreme abrasion and high-impact working environments.
2. What industries commonly use NM500 steel plates?
It is widely used in mining machinery, construction equipment, cement plants, loading machines, dump trucks, and heavy material handling systems.
3. What are the main advantages of NM500 steel?
It provides excellent wear resistance, high impact toughness, extended service life, and helps significantly reduce equipment downtime and maintenance costs.
4. Can NM500 steel be cut and processed?
Yes, it can be cut by laser, plasma, or flame, and also supports welding and forming with proper processing techniques.
5. Is NM500 suitable for high-impact applications?
Yes, it is specifically designed to withstand both strong abrasion and heavy impact conditions in harsh industrial environments.
6. What is the difference between NM500 and lower-grade wear plates?
Compared with lower hardness grades like NM400, NM500 offers significantly higher wear resistance, making it more suitable for extreme working conditions.
